WIDMX 512 Series is unique in its use of advance radio technologies that are also used in military communication and mobile phones. Its user-friendly operation that simplifies all the complex communication protocols makes it ossible for the users to plug and play.
  • Specifications
  • Video
    Band: 2.402GHz – 2.480GHz, ISM, 79 channels
    Spread spectrum: FHSS, 1100 hops / sec
    Modulation: GFSK
    Maximum Transmit Power: 23dBm
    Receiver Sensitivity: -94dBm
    Power: DC 5V ± 10%
    Size: 150 x 115 x 50mm

    2.4GHz ISM Band, license-free worldwide
    FHSS with 79 Channels, interference-free operation
    32-bit ARM processor, DMA transfer without delay
    Standard DMX512 3-pin XLR, 5-pin XLR, transceiver
    Built-in Wireless Solution compatibility mode
    Group  Mode,  easy  plug-and-play  operation;
    Pairing Mode, supports more transmitter universes
